8. Tangents

Properties	Figure
Property 1:From any external point, exactly two tangents can be drawn to meet a circle. The length of the these two tangents are equal. Here, from external point P, PA and PB are the only tangents that can be drawn and PA $=$ PB
Property 2:From any point on a circle, only one tangent can be drawn. Here, through the points A, B and C that lie on the circle the only tangents that can be drawn are $x, y$ and $z$ respectively.
Property 3:The line connecting the centre of the circle to the point where a tangent meets the circle is perpendicular to the tangent. $t$ is the tangent passing through B. Therefore, OB is perpendicular to $t$.
Property 4:If two tangents are drawn to a circle from an external point, then the line joining the the centre of the circle and this external point, 1) bisects the angle subtended by the tangents at the external point 2) bisects the central angle formed by the points where the common tangents touch the circle 3) is perpendicular to the line formed by joining the points where the common tangents touch the circle PA and PB are the two common tangents that touch the circle at A and B respectively. O is the centre of the circle. So, 1) $\angle$APO $=$ $\angle$BPO 2) $\angle$AOP $=$ $\angle$BOP 3) AB is perpendicular to PO
Tangent-Secant Theorem:If a tangent and a secant are drawn to a circle from an external point, then the square of the length of the tangent equals the product of distances of the external point to the two intersection points of the circle. Here, PT is the tangent of the circle and PB is the secant intersecting the circle at A and B. So, PT$^{2}$ $=$ PA $\times$ PB.
Alternate Segment Theorem : The angle subtended by a chord and a tangent on one side equals the angle subtended by the chord in the alternate segment. Here, XY is the tangent intersecting the circle at B. BC and BD are two chords. So, $\angle$DBX $=$ $\angle$BCD and $\angle$CBY $=$ $\angle$BDC.

Example 10 to 12

In the adjoining diagram, I and II are circles with centres P and Q respectively. The two circles touch each other and have a common tangent that touches them at points R and S respectively. This common tangent meets the line joining P and Q at O. The diameters of I and II are in the ratio $4 : 3$. It is also known that the length of PO is $28$ cm
[CAT 2004]

10) What is the ratio of the length of PQ to that of QO?

(1) $1 : 4$                     (2) $1 : 3$                     (3) $3 : 8$                      (4) $3 : 4$

11) What is the radius of circle II?

(1) $2$ cm                    (2) $3$ cm                    (3) $4$ cm                      (4) $$5 cm

12) The length of SO is

(1) $8\sqrt{3}$cm              (2) $10\sqrt{3}$cm              (3) $12\sqrt{3}$cm               (4) $14\sqrt{3}$cm

Solution

PR and QS are the radii of circles I and II. Also, PR and QS are perpendicular to the tangent OR. As the ratio of diameters of the circles is $4 : 3$, let the radii PR and QS be $4x$ and $3x$ respectively. $\triangle$OSQ ~ $\triangle$ORP [As $\angle$OSQ $=$ $\angle$ORP $=$ $90^\mathrm{o}$ & $\angle$O is common) $\dfrac{OQ}{OP} = \dfrac{QS}{PR}$ ⇒ $\dfrac{OP - 7x}{OP} = \dfrac{3x}{4x}$
As OP $= 28$, ⇒ $\dfrac{28 -7x}{28} = \dfrac{3}{4}$ ⇒ $x = 1$ $\therefore$ PR $= 4$ cm, QS $= 3$ cm, PQ $= 7$ cm & QO $=$ $28 - 7 = 21$ cm 10) PQ : QO $=$ $7 : 21 = \bm{1 : 3}$

11) Radius of circle II $=$ QS $=$ $\bm{3}$ cm

12) $\triangle$OSQ is a right-angled triangle. Therefore, applying Pythagoras theorem,
OS$^{2}$ + QS$^{2}$ $=$ OQ$^{2}$
⇒ OS$^{2} + 3^{2}$ $=$ $21^{2}$ ⇒ OS $=$ $\sqrt{432} = \bm{12\sqrt{3}}$ cm

Answer: 10) (2) $1 : 3$ ; 11) (2) $3$ cm ; 12) (3) $12\sqrt{3}$ cm

Example 13

From an external point P, the $2$ tangents drawn to the circle with centre O meet the circle at points A and B such that $\angle$APB $=$ $30^\mathrm{o}$. A third tangent drawn through a point on the minor arc AB intersects PA and PB at C and D respectively. What is $\angle$COD?

Solution

The line from the centre to a point on the circle is perpendicular to the tangent that passes through the point.
$\therefore$ PA $\perp$ OA, PB $\perp$ OB & CD $\perp$ OE

Sum of interior angles of quadrilateral OAPB $=$ $360^\mathrm{o}$

⇒ $\angle$AOB + $\angle$PAO + $\angle$BPA + $\angle$OBP $=$ $360^\mathrm{o}$
⇒ $\angle$AOB + $90^\mathrm{o} + 30^\mathrm{o} + 90^\mathrm{o} =$ $360^\mathrm{o}$
⇒ $\bm{\angle}$AOB $\bm{= 150^\mathrm{o}}$

CE $=$ CA, OE $=$ OA and $\angle$CEO $=$ $\angle$CAO $=$ $90^\mathrm{o}$
$\triangle$COE ≅ $\triangle$COA (SAS congruency)

$\therefore$ $\angle$AOC $=$ $\angle$COE $=$ $\dfrac{1}{2} \times$ $\angle$AOE

Likewise, $\triangle$DOE ≅ $\triangle$DOB (SAS congruency)

$\therefore$ $\angle$BOD $=$ $\angle$DOE $=$ $\dfrac{1}{2} \times$ $\angle$BOE

$\angle$COD $=$ $\angle$COE $+$ $\angle$DOE $=$ $\dfrac{1}{2} \times$ $\angle$AOE $+$ $\dfrac{1}{2} \times$ $\angle$BOE

$=$ $\dfrac{1}{2} \times$ ($\angle$AOE $+$ $\angle$BOE ) $=$ $\dfrac{1}{2} \times$ $\angle$AOB

$=$ $\dfrac{1}{2} \times 150 = \bm{75^\mathrm{o}}$

Answer: $75^\mathrm{o}$

Example 14

In the adjoining figure, the rectangle at the corner measures $10$ cm $\times 20$ cm. The corner A of the rectangle is also a point on the circumference of the circle. What is the radius of the circle in cm?
[CAT 2003L]

(1) $10$ cm (2) $40$ cm (3) $50$ cm (4) None of the above

Solution

Let the radius of the circle be $r$ cm.

When the vertical side is extended down and a line is drawn from the centre O that is parallel to the $20$ cm side, the two lines are perpendicular to each other.

We now get a right-angled triangle with r being the hypotenuse. The other $2$ sides are $(r - 10)$ cm and $(r - 20)$ cm.

Substituting values, we note that $r = 50$ cm results in the other $2$ sides being $40$ cm and $30$ cm.

As $30^{2} + 40^{2} = 50^{2}$, $\bm{r = 50}$ cm is the answer.

Answer: (3) $50$ cm
